Decorative round luminaire
The luminaire comprises a die-cast aluminum housing
with a black finish, engineered for ground-recessed
applications. It incorporates a clear tempered glass diffuser and a PMMA reflector
| Installation | Anchor base pole |
|---|---|
| IP Rating | IP65 |
| IK Rating | 09 |
| CRI | 90 |
| Finishing Color | 01 - Black 02 - Dark grey 03 - White 04 - Matt sliver 05 - Bronze |
| Material | die-cast Aluminum |
| Diffuser material | Transparent glass |
| Reflector material | Faceted aluminum |
| Lighting source | COB |
| lighting Emission | Direct symmetric Light emission angle (º): 77.5 |
| Power | 20W |
| Color temperature | 3000K-4000K-6500K |
| Output Lumen Flux | 2438.8lm |
| Beam angle | 77.5º |
| Safety class | Class III |
| Lifetime | 50000H |
| Warranty | 3 years |
| Mains Frequncy | 50HZ |
| Mains Voltage | 220-240V AC |
| Comment |
