Decorative round luminaire
The luminaire is constructed from durable die-cast
aluminium with a sleek black electrostatic powder-coated
finish, designed for recessed mounting, a clear tempered
glass diffuser the optical system includes a PMMA
| Installation | Ceiling |
|---|---|
| IP Rating | IP65 |
| IK Rating | 08 |
| CRI | 90 |
| Finishing Color | 01 - Black 02 - Dark grey 03 - White 04 - Matt sliver 05 - Bronze |
| Material | Aluminum |
| Diffuser material | Transparent glass |
| Reflector material | Faceted aluminum |
| Lighting source | COB |
| lighting Emission | Direct symmetric Light emission angle (º): 32 ° |
| Power | 10 w |
| Color temperature | 3000K-4000K-6500K |
| Output Lumen Flux | 581.5 lm |
| Beam angle | 32º |
| Safety class | Class III |
| Lifetime | 50000H |
| Warranty | 3 years |
| Mains Frequncy | 50HZ |
| Mains Voltage | 220-240V AC |
